RECIRCULATING CHILLER
Make Dinesh Scientific Model DS-RC-4
PRODUCT DESCRIPTION
These powerful chillers provide enough heat removal to simultaneously cool two rotary evaporators. Safety features include user-adjustable high-temperature limit and alarm auto-restart on power failure, and a fixed low flow rate alarm with power cutoff. This machine is a compressor cooling, heat exchange with the water; reduce the temperature of the water pumped out through the loop. Temperature controller for temperature control with the three functions of the thermostat, cooling, circulation. Recirculating chillers are a popular choice for temperature-critical applications because they offer stable temperature control, a constant flow rate and constant pressure control. Many process heating systems require cooling as well as heating. For example, many conveyor ovens feature a cooling zone
FEATURES
- Optimum performance
- Dimensional accuracy
- Sturdy construction
- Both sides folding handle for easy movement
- Overheat protection and liquid level alarm function
- Stainless steel inner tank
- Waterlevel alarm function
- Fast cooling, low noise,low vibration,stable and reliable performance
TECHNICAL DATA:
| PARAMETER | VALUE |
| Compact recirculating chiller | minimum 400 W @ 20⁰C Cooling |
| Green environment friendly natural Coolant like | R290 |
| Cooling capacity | @20°C 400W |
| Working temperature Range | -10⁰C to room temp |
| Temperature control | PT1000 |
| Working temperature sensor | PT1000 |
| Working temperature display | LED |
| Temperature stability | 0.5⁰C |
| Display resolution | 0.1⁰C |
| Set temperature resolution | 0.1⁰C |
| Chiller Reservoir Volume | 3-4 Litre |
| Pump type | Pressure-suction pump |
| Circulation Pump pressure max. (discharge Side) | 0.35-0.4 Bar |
| Circulation Pump Pressure (suction side) | 0.15 to 0.2 Bar |
| Pump Flow rate | 17-18 Lit/Min |
| Protection class | IP 21 |
| Interface | RS 232 interface & USB interface both will be there in the system. |
| Power | Voltage [V] 230, Frequency [Hz] 50/60, Power input [W] 250 |
