Recirculating chiller
Model -DS–RC-7
PRODUCT DESCRIPTION
These powerful chillers provide enough heat removal to simultaneously cool two rotary evaporators. Safety features include user-adjustable high-temperature limit and alarm auto-restart on power failure, and a fixed low flow rate alarm with power cutoff. This machine is a compressor cooling, heat exchange with the water; reduce the temperature of the water pumped out through the loop. Temperature controller for temperature control with the three functions of the thermostat, cooling, circulation. Recirculating chillers are a popular choice
for temperature-critical applications because they offer stable temperature control, a constant flow rate and constant pressure control. Many process heating systems require cooling as well as heating. For example, many conveyor ovens feature a cooling zone
SALIENT FEATURES:
- Optimum performance
- Dimensional accuracy
- Sturdy construction
- Both sides folding handle for easy movement
- Overheat protection and liquid level alarm function
- Stainless steel inner tank
- Water Level alarm function
- Fast cooling, low noise,low vibration,stable and reliable performance
SCOPE OF APPLICATIONS:
IT is used in Petroleum, Chemical, Electronic Instrumentation, Physics, Chemistry,
Bioengineering, Medical and health, Life sciences, Light industry food property testing and chemical analysis, research departments, universities, enterprise quality inspection and production department.
TECHNICAL DATA:
| PARAMETERS | VALUES |
| Type | Movable with wheels |
| Temperature Controller | Digital |
| Pump Material | Stainless Steel |
| Type of Pump | Turbine pump |
| Tank capacity/Reservoir Volume | 7.2 liter |
| Noise level, dB (max) | 55-58 |
| Heater Capacity (Kw) | 4.6- 5.0 kiloWatt |
| Cooling capacity at 10 degree Celsius(watt) | 500 Watt |
| Pressure (Bar) | 4.0- 4.1 bar |
| Cooling Capacity frequency | 50 Hertz |
| Refrigerant | R134A |
| Pumping Capacity, lpm | 9.5-10.0 |
| Pumping Capacity frequency | 50 Hertz |
| Electrical Requirement, Operating Voltage | 230 Volt, (Number of Phase 1) |
| Frequency | 50 Hertz |
| Heater Voltage requirement | 230 |
| Standard Temperature Range | 40 degree Celsius |
| Temperature Stability, degree Celsius | 0.1 degree Celsius |
| Pump protection due to low level of coolant | Yes |
| Leak Proof Recirculation of cold water to and from condenser | Yes |
| Inlet/outlet | 1/2 inch female NPT (Drain 1/4 inch female NPT) |
| Deionization filter | Yes |
