GEL DOCUMENTATION SYSTEM

MAKE DINESH SCIENTIFIC

DESCRIPTION

A specialized lab tool called a Gel Documentation System is used to see and record protein and nucleic acid samples that have been separated using gel electrophoresis. Labs that study biochemistry and molecular biology frequently use this approach. A high-resolution camera, image software, and a UV or white light transilluminator are usually the main parts of a gel documentation system.

TRANSILLUMINATOR:

• To illuminate the gels, the system is fitted with a transilluminator that emits either white light or ultraviolet (UV) radiation. White light works well for protein gels, however UV light is typically utilized for DNA and RNA gels.

CAMERA:

• To take crisp, in-depth pictures of the segregated biomolecules inside the gel, a high-resolution camera is built into the device. The particular wavelengths that fluorescent dyes, which are frequently employed to stain DNA, RNA, or proteins, emit are detectable by the camera.

FILTERS:

• Gel Documentation Systems frequently come with replaceable filters that can be used to catch particular light wavelengths, making it possible to see various fluorophores.

IMAGE SOFTWARE:

• Specialist imaging software is used to process and analyze the acquired images. With the aid of this software, researchers may measure and record outcomes, such as the length and width of protein lanes or DNA bands on the gel.

DOCUMENTATION:

• Film-based photography and other conventional techniques are no longer necessary thanks to Gel Documentation Systems, which make it easier to digitally record gel electrophoresis data. Gel pictures can be electronically saved, arranged, and shared by researchers.

VERSATILITY:

• Certain Gel Documentation Systems are made flexible enough to meet varied experimental needs by accommodating a range of gel types and sizes.

HIGH-SPECTRUM CAMERA:

• Clear and detailed photos of the separated biomolecules in the gel are captured using an integrated high-resolution camera.

SOURCES OF EXCITATION AND FILTERS:

• Different fluorescent dyes used to stain DNA, RNA, and proteins can be accommodated by interchangeable filters and numerous excitation sources. Because of this adaptability, researchers can see different kinds of samples.

FEATURES :

• No light seepage Darkroom
• Dimensions outside: 44x40x72cm
• CCD Lens
• CCD Science
• 5 Megapixel, 2592*1944 resolution
• 16-bit A/D (65,536 greyscales)
• High QE: 75%
• Noise in reads: 5.1e-RMS
• SNR: 70.1 dB
• Sensitivity (2.7): EB < 10 pg DNA staining
• Imported 2/3-Inch Computer, F1.2 Automated Lens
• Aperture and Focus Numbers
• The usual filter for gel documents is 590 nm.
• White LED * 2 Epi-white light Lamp
• Standard UV transmission: Wavelength: 302 nm; Area: 21 x 26 cm
• Optional white LED light, 21 x 19 cm
• Optional Blue LED: 21 x 19 cm
• UV shield as a standard feature
• Gel Doc program
• Software for analysis
• Application (often included)
