ELECTRIC TSET BENCH
MAKE DINESH SCIENTIFIC
MODEL DS-ETB-200
DESCRIPTION
A specialized piece of furniture made for electrical and electronic work, an electric workbench offers a secure, well-organized, and useful workspace for a range of jobs. Here’s a thorough explanation:
KEY FEATURES:
STURDY CONSTRUCTION:
Usually constructed from sturdy materials like steel, solid wood, or a mix of the two.
A sturdy, level work table for parts and tools.
ELECTRICAL OUTLETS AND POWER STRIPS:
Power strips and built-in outlets provide convenient access to electricity.
surge protectors to prevent spikes in electricity.
LIGHTING:
Integrated lighting to provide a well-lit workstation, frequently with movable LED lamps.
Occasionally comes with magnifying lamps for close work.
PURPOSE
Overhauling, testing and servicing of electronics sub assemblies used in T90 Tank in the new proposed Equipment testing Lab and Electrical & Electronics units overhaul lab.
ESD (ELECTROSTATIC DISCHARGE) PROTECTION:
Grounding points and ESD mats are useful tools for shielding delicate electronic parts.
To avoid static build-up, use grounding cables and wrist straps.
SCOPE OF SUPPLY:
Work Bench with chair
5.5 Digit Digital Multi Meter
Programmable DC power supply
Soldering and Re-Work station:1 No.
Hipot Tester 1No.
Standard accessories
Documents of assembly, electrical maintenance manual, operating manual etc.,
Recommended Maintenance Spares as ordered
All the Accessories for the above instruments
Erection and commissioning
Packing and transportation to HVF
Commissioning of equipment at HVF Work place and performance prove-out of the offered equipment by supplier’s representative.
TECHNICAL DETAILS:
MODEL DS-ETB-200
Construction Robust and well-proven construction that can withstand harsh environmental and labor conditions.
Design Modular design with plug-in PCBs housed with complete protection preventing all possible damages.
5 % DIGITAL MULTIMETER
Digits 5.5 digit
Counts 200000
AC Voltage Accuracy (% of Rdg + % Rng) ±(0.2% + 0.05%) @ 45Hz – 20kHz frequency range and 200V range
DC Current Range 200pA – 10A
AC Current Range 20mA – 10A
Digits 5.5 digit
Counts 200000
Hipot Tester
No. of Channels SI
AC Withstanding Voltage Test >5kV
DC Withstanding Voltage Test >6kV
Resolution 0.05kV
Current Test Range (AC) 20.00mA
Current Test Range (DC) 10.00mA
Output Voltage for Insulation Resistance Test from 0.1kV to 1kV
Resistance Test Range Between 1MΩ and 9999MΩ
Arc Detection (AC and DC) Configurable across 1 to 9 levels
Settable Voltage Rise Time between 0.1 and 999.9 seconds
Test Time Setting (AC, DC) 0.2 – 999.9 sec
Waiting Time (IR) 0.2 – 999.9 sec
Standard Interface Handler/PLC, USB
Measurement Ranges and Basic Accuracy
DC Voltage Range 200mV – 1000V
DC Voltage Accuracy (% of Rdg + % Rng) ±(0.015% + 0.003%) @ 200V range
AC Voltage Range 200mV – 750V
Frequency Accuracy (% of Rdg + % Rng) ±(0.01% + 0.003%) @ 200kHz frequency range
Continuity Range 2000Ω
Continuity Accuracy (% of Rdg + % Rng) ±(0.05% + 0.01%)
AC Current Accuracy (% of Rdg + % Rng) ±(0.50% + 0.10%) @ 45Hz to 2kHz frequency range and 200mA range
Resistance Range 200Ω – 100MΩ
Resistance Accuracy (% of Rdg + % Rng) ±(0.02% + 0.01%) @ 200kΩ range
Frequency Range 20Hz – 1MHz
Diode Range 2V
Diode Accuracy (% of Rdg + % Rng) ±(0.05% + 0.01%)
General Specifications
Power Supply (100-240) AC 50Hz/60Hz
Consumption 20 VA max
Interface LAN/USB
Weight 1600W
Power Factor >0.99 @ full load
Efficiency ≤82%
Load Regulation CV mode: ≤5mV; CC mode: ≤11mA
Line Regulation CV mode: <2mV; CC mode: ≤3mA
Ripple CV mode: ≤9mV rms; CC mode: ≤51mA rms (5Hz ~ 1MHz)
Programming Speed (100% Load)
Rise Time <22 ms for output voltage change from 10% to 90%
Fall Time <22 ms for output voltage change from 90% to 10%
Temperature Coefficient CV: ≤80 ppm/°C (after 30 min of warm-up time and during 8 hrs)
CC: ≤80 ppm/°C
Analog Programming Voltage Programming: 0 – 5V
Current Programming: 0 – 5V
Output Stability CV: <100 ppm (after 30 min of warm-up time and during 8 hrs)
CC: <100 ppm
Protections Over voltage, Over current, Short circuit, Over temperature
Programming Interfaces Analog programming
Display 3-digit simultaneous display for both Voltage and Current
Operating Temperature 0 to 50°C
Front Panel Controls Mains ON/OFF, Voltage and Current setting with multi-turn potentiometer (Coarse and Fine), OVP Setting
Front Panel Indicators Voltage, Current, CV, CC, Output ON, OVP, ACF, OTP
Cooling Forced air cooling with variable fan speed
Station Type All-in-one station for soldering and rework
Dimensions 19” rack mountable, 11U height
Included Components Vacuum pump, soldering station, and corresponding handles
Soldering Station Two soldering tools can be connected to this control station and utilized simultaneously.
Power Output 150W available for both tools
Display Large display with easy management of temperatures and settings
User Settings Extensive menu to modify various user settings, with the ability to link settings to specific tools
Automatic Tool Recognition Station automatically sets the desired properties when a soldering iron is connected
Soldering Iron Supplied with two irons featuring a comfortable grip for easy use
Tip Technology Active tips for better heat transmission
Work Surface 18mm laminated wooden top with an anti-static mat, providing a sufficient working area.
De-soldering Equipped with an MSE-A vacuum pump delivering 9 SLPM suction, connected to the soldering station with a de-soldering iron.
De-soldering Tips Various tips available, starting at a 0.6mm diameter, suitable for SMD component de-soldering.
Handles & stands Corresponding handles and stands provided for all applications, with automatic switch-off when placed in the stand, prolonging tip lifespan.
Hot Tip Handling Stands include handles for changing hot tips.
Overall Dimensions 1500mm (W) × 900mm (D) × 1500mm (H)
Structure Heavy-duty welded 30 × 30 × 1.6mm tubular mild steel construction for durability.
Major Specifications
Frame Two-color epoxy-coated 1.6mm mild steel tubular structure.
Panels Epoxy-coated 1.0mm mild steel back and top panels.
Tabletop Thickness 18mm laminated wooden top.
Tabletop Height 750mm (with leveling screws).
Working Area 1500mm × 750mm.
Storage One pull-out, channel-mounted drawer with a lock.
I/O Sockets Provided on the front for all instruments.
Workstation Dimensions
Width 1500mm
Height 1500mm (overall workstation height)
Depth 900mm
Electrical Panel
Switch Sockets Six 5/15A modular switch sockets.
MCB 32A modular DP MCB for overload protection.
Power Indicator LED indicator for mains power on.
Power Cord 3-meter length.
Work Surface Feature Anti-static mat on the working area.
ACCESSORIES
Work Bench and Chair 1 No.
5.5 Digit Digital Multimeter 1 No.
Programmable DC Power Supply 1 No.
Soldering and Re-workstation 1 No.
Hipot Tester 1 No.
All Accessories for the Above Instruments Included
